Rack Power Distribution · RTX-C13L
RTX-C13L Snap-In IEC C13 Locking Outlet Modules
Snap-in IEC C13 outlet modules with a push-release locking feature that helps keep C14 plugs seated in PDUs, inverters and equipment panels.
NoteAC250V / 15A
Puissance3750W
Contacts3
MontageSnap-in panel cutout
Présentation du produit
The RTX-C13L is a single IEC C13 receptacle with an anti-dislodge locking function released by a push button. It snaps into a panel cutout, making it suitable for rack PDUs, inverter outputs and equipment power panels where accidental plug removal must be avoided.
Caractéristiques principales
- Locking C13 receptacle with push-to-release button
- AC250V, 15A supplier rating
- Three contacts for line, neutral and earth
- Snap-in mounting for panel cutouts
Modèles / configurations disponibles
Use these RITOKS configuration references for enquiry; confirm the exact specification before ordering.
| Référence RITOKS | Outlet type | Note | Contacts |
|---|---|---|---|
| RTX-C13L | IEC C13, locking | AC250V / 15A / 3750W | 3 |
Caractéristiques techniques
| Outlet standard | IEC C13 with locking function |
|---|---|
| Tension nominale | AC 250 V |
| Courant nominal | 15A |
| Rated power | 3750W |
| Poles / contacts | 3 |
| Montage | Snap-in panel cutout |
| Cutout dimensions | Not published; confirm with ritoks before ordering |
Applications
AI-generated conceptual application context. Confirm equipment fit, installation conditions and circuit requirements for the selected configuration.
Rack PDU assemblies
Build C13 outlet strips that keep server and switch cords in place.
Inverter AC outputs
Provide a locking IEC output on inverter and UPS front panels.
Test and lab equipment
Reduce accidental unplugging on benches with frequent cable movement.
Informations à vérifier pour la sélection
- Panel cutout size and panel thickness
- Compatible C14 plug and cord set
- Termination type and wiring
- Quantity and certification requirements
FAQ
Does the lock work with any C14 plug?
It is designed for IEC C14 plugs; test the plug body you plan to use before volume orders.
Quelle découpe doit-on prévoir dans le panneau ?
Cutout dimensions are not published. Request the drawing before designing the panel.
Produits associés
Demander un devis
Veuillez nous indiquer le modèle exact, les puissances nominales requises, la quantité et la destination. Nous vérifierons la disponibilité et les documents nécessaires avant de vous établir un devis.
