RTX-DLC DC-Link Film Capacitors
Dry resin-filled polypropylene film capacitors for DC-link circuits. The selected table row is 110 µF at 550 V DC at 85 °C; voltage and temperature must be considered together.
110 µFSelected capacitance
550 V DCAt 85 °C
4 leadsSelected configuration
PP filmDielectric
Product Overview
Dry resin-filled polypropylene film capacitors for DC-link circuits. The selected table row is 110 µF at 550 V DC at 85 °C; voltage and temperature must be considered together. The listed electrical and dimensional values apply only to the selected 110 µF table row, not every family configuration.
Key Features
- Selected capacitance: 110 µF
- Selected rated voltage: 550 V DC at 85 °C; 600 V at 70 °C
- Lead configuration: 4 wires, Ø1.2 mm
- Dimensions: 57.5 × 35 × 50 mm
- Lead pitch: P1 52.5 mm / P2 20.3 mm
Available Models / Configurations
Use these configuration references for enquiry; confirm the exact specification before ordering.
| RITOKS configuration reference | Configuration | Selection notes |
|---|---|---|
| RTX-DLC110-550 | 110 µF / 550 V DC at 85 °C | Four-wire selected table row |
Technical Specifications
| Selected capacitance | 110 µF |
|---|---|
| Selected rated voltage | 550 V DC at 85 °C; 600 V at 70 °C |
| Lead configuration | 4 wires, Ø1.2 mm |
| Dimensions | 57.5 × 35 × 50 mm |
| Lead pitch | P1 52.5 mm / P2 20.3 mm |
| ESR | 3 mΩ for selected row |
| ESL | 15 nH for selected row |
| RMS current | 23 A at 10 kHz and 85 °C |
| Peak current | 2200 A for selected row |
Applications
AI-generated conceptual application context, not a photograph of an actual installation. Confirm equipment fit and circuit requirements for the selected configuration.
Solar Inverters
Match DC-link voltage, ripple duty and operating temperature.
Power Conversion Assemblies
Review lead geometry and parasitic characteristics against circuit needs.
Converter Maintenance
Confirm exact capacitance, dimensions and duty before replacement.
Information to Confirm for Selection
- DC voltage, capacitance and ripple-current spectrum
- Ambient and capacitor operating temperature
- Lead pitch and mechanical clearance
- Lifetime requirement and supporting datasheet
FAQ
What information is needed for a quotation?
DC voltage, capacitance and ripple-current spectrum Please include quantity and destination.
What should be confirmed before selecting a configuration?
The listed electrical and dimensional values apply only to the selected 110 µF table row, not every family configuration.
